SP Wilmad Labglass
NMR Quartz Tubes, 5 mm, Wilmad, Precision | Ext. Ø: 4,9365 mm ± 0.0065
Article number: 4682855
Product information "NMR Quartz Tubes, 5 mm, Wilmad, Precision | Ext. Ø: 4,9365 mm ± 0.0065"
Thin-walled Precision Quartz NMR tubes. To maximize Signal-Noise-Ratio, Precision NMR Tubes have minimal paramagnetic impurities that would impact shimming. The Quartz tubes have an extremely low thermal expansion rate and high tensile strength which is 14 times more robust during the cooling/heating process than Type 1 Class A glass tubes.
- Low Boron density at or below 0.1 ppm guarantees a clean background in Boron-11 NMR studies
- Inner surface is resistant to strong acid and base at ambient temperature
- For temperatures up to 1300˚C and variable temperature experiments that have a temperature step over 120˚C
- Includes disposable caps
Camber: | 25 µm |
---|---|
Concentricity: | 51 µm |
Ext. Ø: | 4,9365 mm |
Ext. Ø: | 4,9365 mm ± 0.0065 |
Frequency: | 300 MHz |
Int. Ø: | 4.2065 mm ± 0.0065 |
Int. Ø: | 4.2065 mm |
Length: | 178 mm |
Material: | Quartz |
Tolerance ext. Ø: | 0.0065 mm |
Wall thickness: | 0.38 mm |
