Freeze dryer in modular design for routine applications in the laboratory. Cooling is done by air-cooled compressor with direct temperature measurement at the cooling surface. A pre-cooling of the condenser is possible to avoid a delayed start or thawing of the samples. Further functions are the display of the vacuum and temperature curves, an error message memory and an operating hours counter.3 program places with 3 drying stages eachOperation via 4,3" colour touch screenDisplayed actual values during operation: Condenser temperature, vacuum (mbar), timeStainless steel housing resistant against commercial disinfectantsCFC-free refrigerantOperating language: English or German, other languages on request.The perfectly matched single parts of the modular system can be combined individually. All required parts of the optional accessories must be ordered separately.SpecificationsIce condenserTemperature:-50 °C or -80 °CIce condensor capacity:2 kg / 24 hmax. ice capacity:3 kgVolume:5.7 lCooling system:one-stage (-50 °C) / two-stage (-80 °C)Material:Stainless steel 1.4404/AiSi316LDimensions (Ø x H ):220 x 150 mmBasic unitWeight:45 or 58 kg (depending on the version ice condenser)Dimensions (W x D x H):490 x 470 x 440 mmPower supply:230 V, 50/60 HzFreeze dryer in modular design for routine applications in the laboratory. Cooling is done by air-cooled compressor with direct temperature measurement at the cooling surface. A pre-cooling of the condenser is possible to avoid a delayed start or thawing of the samples. Further functions are the display of the vacuum and temperature curves, an error message memory and an operating hours counter.3 program places with 3 drying stages eachOperation via 4,3" colour touch screenDisplayed actual values during operation: Condenser temperature, vacuum (mbar), timeStainless steel housing resistant against commercial disinfectantsCFC-free refrigerantOperating language: English or German, other languages on request.The perfectly matched single parts of the modular system can be combined individually. All required parts of the optional accessories must be ordered separately.Hazardous Substance DataUNNR3358

Freeze dryer in modular design for routine applications in the laboratory. Cooling is done by air-cooled compressor with direct temperature measurement at the cooling surface. A pre-cooling of the condenser is possible to avoid a delayed start or thawing of the samples. Further functions are the display of the vacuum and temperature curves, an error message memory and an operating hours counter.3 program places with 3 drying stages eachOperation via 4,3" colour touch screenDisplayed actual values during operation: Condenser temperature, vacuum (mbar), timeStainless steel housing resistant against commercial disinfectantsCFC-free refrigerantOperating language: English or German, other languages on request.-Adjustable parameters for each drying stage: Hold-up time, vacuum setpoint, shelf space temperature (with the option heated shelf spaces)The perfectly matched single parts of the modular system can be combined individually. All required parts of the optional accessories must be ordered separately.SpecificationsIce condenserTemperature:-50 °C or -80 °CIce condensor capacity:5 kg / 24 hmax. ice capacity:8 kgVolume:16 lCooling system:one-stage (-50 °C) / two-stage (-80 °C)Material:Stainless steel 1.4404/AiSi316LDimensions (Ø x H ):270 x 280 mmBasic unitWeight:60 or 75 kg (depending on the version ice condenser)Dimensions (W x D x H):800 x 530 x 400 mmPower supply:230 V, 50/60 Hz

Freeze dryer in modular design for routine applications in the laboratory. Cooling is done by air-cooled compressor with direct temperature measurement at the cooling surface. A pre-cooling of the condenser is possible to avoid a delayed start or thawing of the samples. Further functions are the display of the vacuum and temperature curves, an error message memory and an operating hours counter.3 program places with 3 drying stages eachOperation via 4,3" colour touch screenDisplayed actual values during operation: Condenser temperature, vacuum (mbar), timeStainless steel housing resistant against commercial disinfectantsCFC-free refrigerantOperating language: English or German, other languages on request.-Adjustable parameters for each drying stage: Hold-up time, vacuum setpoint, (shelf space temperature (with the option heated shelf spaces) -Automatic defrosting of the ice condenser-Variable shelf spaceThe perfectly matched single parts of the modular system can be combined individually. All required parts of the optional accessories must be ordered separately.SpecificationsIce condenserTemperature:-50 °C or -80 °CIce condensor capacity:15 kg / 24 hmax. ice capacity:20 kgVolume:50 lCooling system:one-stage (-50 °C) / two-stage (-80 °C)Material:Stainless steel 1.4404/AiSi316LDimensions (Ø x H ):400 x 400 mmBasic unitWeight:75 or 90 kg (depending on the version ice condenser)Dimensions (W x D x H):750 x 750 x 900 mmPower supply:230 V, 50/60 Hz (-50 °C) / 400 V, 50/60 Hz (-80 °C)
